Nikon N Series 5″ Total Station with Full Accessories

Features and Benefits

  • Angular Accuracy of 5”
  • Reflectorless range of up to 1.968 ft
  • Single-Prism range up to 13,123 ft
  • Internal memory up to 50,000 records
  • Built-in Bluetooth connectivity
  • IP55 Protection Class
  • Up to 22 hours Li-ion Battery Life
  • Optional Dual Display

Download Datasheets

Download Brochures


Product total
Options total
Grand total

Product Description

Overview for the Nikon N Series 5″ Total Station

The Nikon N Series Total Station is an advanced EDM designed to make surveying quick and easy. You have two options to operate the device: the prism mode has a range of 13,000 feet while the reflectorless option works up to 1,900 feet. You can choose between 2” and 5” accuracy so that the total station will fit your application.

Easy Operation The N Series comes with a laser pointer for faster locking on target. Nikon’s onboard software collects up to 50,000 data points and can be transferred wirelessly via Bluetooth. Simply tap your phone on the NFC sensor, and it will automatically connect to the total station.

The Total Station File Transfer app for iOS and Android devices allows you to transfer coordinate data to the N Series. It also captures the collected information from the EDM for transmission to your office. All these features make your work more efficient and save you time.

Rugged and Reliable Built to standard with IP55 dust and water protection, you can confidently use this in the field even in inclement weather. For added security, a rain/dust cover is included in the package for harsher environs. In cases where you need assistance, Nikon’s excellent customer support and service network will ensure that your devices are up to the task.

Flexible Battery and Power Options The device comes with a single replaceable Li-ion battery that lasts up to 14 hours of continuous use. You can use any Type-C USB charging port, like the charger on your vehicle or your power bank, to recharge the batteries.

Configuration Options

The Nikon N Series Total Stations comes in two options. Please choose your preference from the menu above.

  • HQA46710: 5” Accuracy (Single Display)


Price for 1 itemAED1,500.00
What's in the Box
  • 1 Nikon N Series Total Station
  • 1 Tribrach
  • 1 Hard plastic case
  • 1 Shoulder strap for the case
  • 1 Li-ion battery
  • 1 Single-slot USB battery charger
  • 1 USB cable for charger
  • 1 Rain/dust cover
  • 1 Lens cap
  • 1 Adjustment pin tool
  • 1 Allen wrench
  • 1 Warranty card
  • 1 Quick start guide
  • 1 Instrument certificate

Specifications for Nikon HQA46710 N Series Total Station

Weight 11 lb
Dimensions 13.1 in x 6.6 in x 6.8 in
Protection Class IP55
Internal Memory 50,000 records
Angle Measurement
Measuring Method/Reading System Prism / Reflectorless
Detection Method Photoelectric detection by incremental encoder
Minimum Reading 1/5/10” (0.2/1/2 mgon)
Accuracy Nikon N 2": 0.6 mgon / Nikon N 5": 1.5 mgon
Diameter of Circle 3.46 in
Distance Measurement
EDM Accuracy (Precision) ±(2+2 ppm × D) mm
Tilt Sensor/Compensator
Range ±3'
Type Dual axis
Method Liquid-electric detection
Power Source Li-on battery
Battery Life Up to 22 hours
Optical Plummet
Image Erect
Magnification 3X
Field of View
Focus Range 0.5 m (1.6 ft) to 8
Circular Bubble Vial 10‘/2 mm
Length of Tube 4.9 in
Image Erect
Diameter of Objective Lens (Aperture) 1.77in
Magnification 30× (18x/36x with optional eyepieces)
Field of View 1°20‘
Resolving Power 3
Minimum Focus Distance 4.9 ft
Display and Keypad
Type LCD Display
Sides Nikon N 2": Both / Nikon N 5": Single
Touchscreen No
Backlight Yes
Pixels 128 × 64 pixel
Operating –4 °F to +122 °F
Measurement Range (under fair weather conditions)
Single Prism 13,123 ft
No Prism 1,968 ft
Bluetooth Integrated




2" Angular Accuracy, Dual Display(HQA46700), 5" Angular Accuracy, Single Display(HQA46710)
