Leica DD120 Series Utility Cable Locator
Features and Benefits
- Detects live underground cables & copper pipes
- Detects up to 10 feet depth
- Frequency modes: 4 operating
- Automatic Pinpointing
- Hazard function
- LCD display with built-in sensor
- IP54 dustproof and water resistant
- Battery life up to 15 hours
Download Datasheets
Download Brochures
Product Description
Overview for Leica DD120 Series Utility Cable Locator
Reliable and precise, the Leica DD120 Series Utility Cable Locator with depth indicator is the best solution for accurately detecting live electrical cables and copper pipes underground. It is ideal for excavation and repair contractors, builders, gas and electric companies, cable tv companies, utility installation, and more. This service locator is able to detect underground installations up to ten feet deep.
For precise detection, the DD100 Series offers up to four operating frequency modes that can track and locate power or radio signals depending on the selected mode. It features an Automatic Pinpointing that provides optimum sensitivity when detecting underground utilities. For additional safety, the DD100 comes with a Hazard Zone function that gives an extra warning to close proximity of buried services and alerts the contractor to any immediate danger.
With an IP54 rating, the Leica utility locator is dustproof and water resistant. It uses six AA alkaline batteries that power the device for up to 15 hours with intermittent use. Also, this underground utility detector features a highly visible LCD display with a built-in light sensor that is an important feature in dark conditions.
Configuration Options
The Leica DD100 Series Utility Cable Locator offers eight packages with varying bundles for your needs. Please select from the drop-down menu above.
- 6014158: Leica DD120 Plumbers Package (50Hz)
- 6014154: Leica DD120 Plumbers Package (50Hz)
- 872939: Leica DD120 Locator Basic Package (60Hz)
- 6014159: Leica DD120 Plumbers Package (60Hz)
- 6014155: Leica DD120 Depth Package (60Hz)
Model # |
DD120 |
|
Transmitter Modes |
8 kHz, 33 kHz | |
Depth Range |
Line: 1′ to 10′ Sonde: 1′ to 10′ |
|
Power |
50Hz or 60Hz | |
Radio |
15 kHz to 60 kHz | |
Auto |
Power, Radio | |
Depth Accuracy |
10% | |
Operating Temperature |
-4 °F to +122 °F (-20 °C to +50 °C) | |
Storage Temperature |
-40°F to +158°F (-40°C to +70°C) | |
Battery |
6 x LR6 AA Alkaline | |
Battery Life |
Up to 15 hours | |
Dimensions |
30″ L x 10″ W x 3.4″ H | |
Weight |
6 lbs (2.7 Kg) | |
What’s Included |
DD120 Plumbers Package (50Hz)
DD120 (50Hz) Depth Package
DD120 (60Hz) Basic Package
DD120 (60Hz) Depth Package
DD120 (60Hz) Plumbers Package
|
|
Features for Leica DD200 Series Smart Utility Cable Locator
- Choice of 4 models
- Easy-to-use powerful underground locator
- Identifies and detect buried utilities and cables
- Depth range up to 23 feet
- Automated pinpointing technology
- Radio frequency: 15 to 60 kHz
- Smart technology
- Tracks power, radio, signal up to 33 kHz
- Transmitter modes up to 4 modes
- GPS feature with 5 types
- Leica DX Shield software
- 8GB internal memory
- Class 2 Bluetooth technology
- IP66 dustproof and water resistant
- 7.4 Li-ion battery
- Up to 20 hours of battery life
- USB connectivity
- Large colored display
Brand
Leica
| Model & Package | DD120(60Hz) Basic Packages(872939), DD120(60Hz) Dept Packages(6014155), DD130(60Hz) Basic Packages(872941), DD130(60Hz) Dept Packages(6014157) |
|---|
